Tektronix TB1052B-EDU User Manual

Reference
Non-EDU model
s
Options Setting s Comments
Source Defines the source of the waveforms
against which
to run the template
waveform
Compare To Specifies the limit test template against
which to compare the signals defined with
the Source m
enu item.
Run/Stop Te
st
Toggles between whether to start or stop
the limit te
st
Template S
etup
Sets up a li
mit test waveform template.
This is the mask signal you define as
the boundary to compare with the input
source si
gnal. Do this before running a
limit test
Action on
Violation
Defines the actions the oscilloscope will
take after detecting a violation
Limit Test
Stop After Defines the conditions that will cause the
oscill
oscope to end limit testing
Data Logging
Sets th
e data logging feature on or off
Sourc
e
Sets t
he signal source to log data from
Duration
Sets t
he time duration of data logging in
half hour increments, from 0.5 hour to 8
hours, or in one hour increments, from 8
hour
s to 24 hours, or to indefinite
Data Logging
Sele
ct Folder
Sets
the folder to save the waveform data
to
Counter Ch1, Ch2, Ch1 Trigger,
Ch2 Trigger
Trend plot
Run/Stop, Source 1, Type
1,
Source 2, Type 2
Plot a graph of one or two m easurements
as
a function of time.
EDU models
Options Setting s Comments
Counter Ch1, Ch2, Ch1 Trigger,
Ch2 Trigger
84 TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual
