Display a Wavefo
rm
Setting the Graticule Style
To set the graticule style, select Disp lay >
Graticule Style, and then select one of the
following sty
les:
Use for quick e
stimate of
waveform parameters.
Use for full-
screen
measurements with
cursors and automatic
readouts wh
en cross
hairs are not needed.
Use for making quick
estimates of waveforms
while leav
ing more room
for automatic readouts
and other data.
Use with automatic
readouts and other
screen tex
t when display
features are not needed.
Setting t
he Trigger Level Marker
1. Select Display > Objects....
2. Select one of the following:
Short displays a short arrow on the
side of the graticule by the active
wavefor
m.
Long dis
plays a horizontal line
across the graticu le.
Off turns off the trigger level marker.
40 TDS6000B & TDS6000C Series Quick Start User Manual
