Application Exa
mples
Application Examples
This section contains ways to use your instrument in common troubleshooting tasks, procedures for using your instrument
with a Tektronix logic analyzer and extending the use of your instrument.
Using the Extended Desktop and OpenChoice Architecture for E fficient
Documentation
Engineers oft
en need to document their lab work for future reference. Instead of saving screen shots and waveform data
to a CD or USB memory device, and then generating a report later, try using the O penChoice architecture to document
your work in real time.
To make your instrument the c enter of your design and documentation process, use the following procedure.
1. Load Microso
ft Word or Excel on your
instrument.
2. Connect a second monitor. (See page 4,
Adding a Second Monitor.)
3. O pen Microsoft Word, and then drag the
Word window onto the extended desktop.
4. Click Te
kScope to restore the instrument
application.
TDS6000B & TDS6000C Series Quick Start User Manual 83
