GPS7 GPS Synchronization and Timecode module
SELECT OUTPUT.
Selects which BLACK output to configure for signal format,
timing, and timecode parameters or selects the HD trilevel sync rate for the
three BLACK outputs. Use the left (◄)orright(►)arrowbuttontoselect
the output you want to configure (BL ACK 1, BLACK 2, BLACK 3, or HD
TRI-LEVEL SYNC RATE), and then press the ENTER button to access the
BLACK submenu (See page 3-122.) or the HD TRI-LEVEL SYNC RATE
submenu (Se
epage3-126.).
GPS SETUP. Sets GPS signal parameters a nd sets the level at which a warning
message will be generated if the GPS/GLONASS s ignal quality deteriorates.
Select this menu item, and then press the ENTER button to access the GPS
SETUP submenu. (See page 3-130.)
TIME SETUP. Provides access to several submenus for setting timing parameters
for the module. Use the left (◄)orright(►) arrow button to select one of the
following submenus, and then press the ENTER button to access the selected
submenu.
TIME OF DAY menu: Use this submenu to set the module time of d ay
reference. (See page 3-133.)
TIME ZONE OFFSET menu: Use this submenu to set the time zone offset
for your location. (See page 3-138.)
DST SCHEDULE menu: Usethissubmenutoconfigure how the module
handles Daylight Saving Time. (See page 3-139.)
PROGRAM TIME menu: Use this submenu to configure the program time
parameters. (See page 3-142.)
JAM SYNC menu: Use this submenu to set parameters for the Jam Sync
function. (See page 3-143.)
LEAP SECOND menu: Use this submenu to configure how the module
handles leap seconds. (See page 3-144.)
EPOCH SELECT menu: Usethissubmenutoconfigure which time epoch
the module will use. (See page 3-145.)
ALARM TIME menu: Use this submenu to configure a time-based alarm.
(See page 3-145.)
ALARM DELAY menu: Use this submenu to configureatimetodefer
reporting errors so that brief e rrors are ignored. (See page 3-146.)
SELECT LTC. Selects which LTC output to configure for timecode parameters.
Use the left (◄)orright(►) arrow button to select the output you want to
configure (LTC 1, LTC 2 , LTC 3, or LTC 4), and then press the ENTER button to
access the LTC submenu for the selected output. (See page 3-148.)
TG8000 Multiformat Test Signal Generator User Manual 3–117
