Available options:
• Reading the settings from the device:
To read the settings from the device, click on the “Read” button. This will read all
settings in all menus.
• Writing the settings into the device:
After changing the settings or entering new settings, to take effect, it is necessary to
write the new settings into the device by clicking on the “Write” button. This will write
the changes only, but all changes made in any menu.
• Adding a new input event:
To add a new input event, click on the “New” button.
• Creating a copy of an existing input event:
To create a copy of the selected input event, click on the “Clone” button. Please note
that the new copy should have a different unique name.
• Editing input event settings:
To edit the settings of the selected input event, click on the “Edit” button.
• Deleting an input event:
To delete the selected input event, click on the “Delete” button.
Please note that after you make changes, you must write the settings into the device
to be applied. For this, click on the “Write” button.
Event:
Name: custom name of the event. The name entered in this section is used for identification of
the given event within the program and in the event logs. The name should not be longer than
20 characters, and the following characters cannot be used: ^ ~ < > = | $ % " '.
Input: the contact input, which will generate the given event.
Type: the type of the event, which can be new or restore. New event will be generated when an
input is activated, and restore event will be generated when it reverts to its normal state.
In the Contact ID protocol, new events are indicated with 1 (or E), and event restorals are indicated
with 3 (or R).
