System Specifications
Guidance and Manufacturer’s Declaration: Electromagnetic Immunity
Immunity Test IEC 60601-1-2
Test Level
Compliance
Level
Electromagnetic Environment
Guidance
Surge
IEC 61000-4-5
± 1 kV line-line
AC Mains
± 2 kV line-earth
AC Mains
± 1 kV line-line
AC Mains
± 2 kV line-earth
AC Mains
Mains power quality should be
that of a typical commercial
or hospital environment. A
temporary loss of function or
degradation or performance that
ceases after the surge event ends
could occur.
RATED Power
frequency
magnetic elds
IEC 61000-4-8
30 A/m
50Hz or 60Hz
30 A/m
50Hz or 60Hz
Power frequency magnetic elds
should be at levels characteristic
of a typical location in a
typical commercial or hospital
environment.
Voltage dips
IEC 61000-4-11
Voltage
interruptions
IEC 61000-4-11
0% U
T
(100% dip U
T
)
0.5 cycles (at 0°,
45°, 90°, 135°,
180°, 225°, 270°
and 315°)
0% U
T
(100% dip U
T
)
1.0 cycle (at 0°)
70% U
T
(30% dip U
T
)
25/30 cycles (at
0° single phase)
0% U
T
(100% dip U
T
)
250/300 cycles
0% U
T
(100% dip U
T
)
0.5 cycles (at 0°,
45°, 90°, 135°,
180°, 225°, 270°
and 315°)
0% U
T
(100% dip U
T
)
2.0 cycle (at 0°)
70% U
T
(30% dip U
T
)
25/30 cycles (at
0° single phase)
0% U
T
(100% dip U
T
)
250/300 cycles
Mains power quality should be
that of a typical commercial
or hospital environment. If the
user of the CDI OneView System
requires continued operation
during power mains interruptions,
it is recommended that the CDI
OneView System be powered from
an uninterruptible power supply
or a battery.
Note: U
T
is the AC mains voltage
prior to application of the test
level.
RF wireless
proximity elds
IEC 61000-4-3
Tested as
specied on page
B-13 using test
methods from
IEC 61000-4-3
Refer to table on
page B-13.
Refer to page B-13,
“Recommended RF Separation
Distance.”
Proximity
magnetic Fields
IEC 61000-4-39
134.2 kHz
Pulse modulation:
2.1 kHz
65 A/m
13.56 MHz
Pulse modulation:
50 kHz
7.5 A/m
134.2 kHz
Pulse modulation:
2.1kHz
65 A/m
13.56 MHz
Pulse modulation:
50 kHz
7.5 A/m
CDI OneView BPM(s), H/S(s) and
Flow Sensor(s) should not be
positioned within six inches of a
device using a magnetic eld (e.g.
an RFID reader).
