C-5
Communication with Other Devices
Pump System Special Instructions
Terumo™
Advanced
Perfusion
System 1
Interfacing with the Terumo™ Advanced Perfusion System 1
can only be done with the CDI interface module (part number
803479). The System 1 Perfusion screen must be congured to
include the CDI module. See the System 1 Operator’s Manual
for instructions on adding the CDI module to a perfusion screen
conguration. The physical connection between the CDI module
of
the System 1 to the CDI OneView System is the same process
as the CDI System 500 or 550.
Make sure the correct interface cable is used (part number
804981), and that it is connected in the proper orientation (see
labels on cable to determine correct orientation).
The CDI uses the following serial port settings to communicate
with System 1: 19200 baud, 8 bits, no parity, 1 stop bit.
To set up the CDI OneView System, select the System 1 HLM in the
Sensor Connections tab.
Terumo™
NEO System
No special instruction available. The customized interface cable is
an accessory of the Terumo NEO System. Follow the instruction of
the Terumo NEO System to make the connection between the CDI
OneView System and Terumo NEO System.
The CDI uses the following serial port settings to communicate
with the NEO: 19200 baud, 8 bits, no parity, 1 stop bit.
LivaNova S5/
C5®
Interfacing with the LivaNova S5/C5 pumping systems requires
use of the LivaNova interface DDD module.
Use the serial interface cable supplied by LivaNova.
The CDI uses the following serial port settings to communicate
with the S5: 9600 baud, 7 bits, no parity, 2 stop bits.
Medtronic
Bio-Console®
560
The Bio-Console interface protocol must be set to:
• 9600 baud
• 8 bits
• no parity 1 stop bit
This is the default setting from the factory. If you believe the
setting has been changed, contact Medtronic Technical Service to
make adjustments.
Use the serial interface cable supplied by Medtronic.
Note: On the Medtronic connector, pin 2 is assumed to be RX (IN)
and pin 3 is TX (OUT). Hardware handshaking is not supported.
