TESTO 6383 - Page 107

7 Parameterizing, adjusting and analyzing software (P2A software)
107
Icon File Explanation
Symbol shows a
transmitter with a white
P for parameter file in
the upper left corner
Parameter
file
<Type> <Serial number>
<Date> <Time>.cfp
File name can be changed.
The name can be selected freely,
but it is recommended that you
retain the reference to the
instrument.
Parameter files are always
marked red; the parameter
values they contain are only
forwarded to the instrument after
being transmitted to the
instrument file.
4 Function buttons: Dialogues on editing and testing the
instrument are opened by means of the buttons.
[Change parameterization] see 7.3.2. Changing
instrument/parameter file.
[Test/analyze transmitter] see 7.3.3. Chapter Analyzing/testing
the transmitter.
[Adjusting the transmitter] see 7.3.4. Chapter Adjusting the
transmitter.
[Transmitter history] see 7.3.5. Transmitter history.
5 File information:
Status
Shown in the window
An instrument file is
selected
Type, serial number, firmware version of the
instrument.
A parameter file is
selected
Type, serial number and firmware version of
instrument for which the parameter file was
created.
Connection status Green = connection is active
Red = connection is inactive
6 Status bar: Shows the current status when editing via the menu
bar.
