4 Transmitter
52
In addition, the analog outputs can be adjusted. For instructions on
how to do this. See also 4.3.2.10. Analog output adjustment. See
also 4.3.2.13. Self adjustment of testo 6615 trace humidity probe.
Also pay attention to 4.3.2.10. Analog output adjustment.
Enter reference value for 1-point adjustment
Please also 4.3.2.8. refer to 1-point adjustment (offset -
humidity/temperature).
1. In the Measuring Mode press SET, select main menu Adjust
with or and confirm selection with SET.
- Reference value % RH is displayed.
2. Press SET, edit value: Scroll one digit to the right using and
increase value of digit by 1 using . Confirm with SET or abort
entry with ESC.
3. Continue to Reference value temp with or .
4. Press SET, Reference value °C or Reference value °F is
displayed.
5. Press SET, edit value: Scroll one digit to the right using and
increase value of digit by 1 using . Confirm with SET or abort
entry with ESC.
6. Continue to Analog Adj. Ch. 1 with or .
7. Continue with the adjustment of the analog outputs (see below,
step 2) or press ESC to return to main menu Adjust.
8. Continue to main menu Reset with or or return to
Measuring Mode with ESC.
Carrying out a 2-point adjustment
1. In measurement mode, press SET, select Main Menu Adjust
with or and confirm selection with SET.
2. Continue to 2 point adj 11/75% or 2 point adj 20/80% with
or .
3. Press SET.
4. Continue to Adjust Point 11%/Adjust Point 20% or Adjust
Point 75%/Adjust Point 80% with or .
5. Confirm query with SET.
- In the display, 2 point adj 11/75% or 2 point adj 20/80%, 1-
point adjustment, Probe reset appear one after the other.
- After a probe reset, the adapted values appear.
Start self-adjustment
The menu item self-adjustment is only visible when a
testo 6615 probe is connected.
