4 Transmitter
53
1. In the Measuring Mode press SET, select Main Menu Adjust
with or and confirm selection with SET.
2. Select Self-adjust with or and confirm with SET.
3. Select Start Self-adjust with or and confirm with SET.
- Self-adjustment starts, the display value and the output value
are “frozen”.
4. Continue to Cycle time with or (see below, step 2) or
press ESC to return to Main Menu Adjust.
Setting cycle time of the self-adjustment
The time span to the next self-adjustment is shown in the status
line of the display approx. every 5 seconds.
1. In the Measuring Mode press SET, select Main Menu Adjust
with or and confirm selection with SET.
2. Select Self-adjust with or and confirm with SET.
3. Select Cycle time with or and confirm with SET.
4. Select the desired value (48h / 24 h / 12 h / 6 h / 1 h / off) with
or , confirm with SET and return to Cycle time.
5. Continue to Error signal on/off with or (see below, step
3) or press ESC to return to Main Menu Adjust.
Performing analog adjustment
1. In the Measuring Mode press SET, select main menu Adjust
with or and confirm selection with SET.
Each channel is adjusted at three points in the analog
range (at 10 %; 50 %; 90°% of the analog scale).
2. Select Analog Adj. Ch. 1 with or and confirm with SET.
3. Use or to select Adj. Point 1.
4. Press SET. Read off multimeter display (e.g. 5601 mA) and
enter this value in the user menu. Do this by scrolling one digit
to the right using and increasing the value of digit by 1 using
. Confirm with SET or abort entry with ESC.
5. Use or to select Adj. Point 2.
6. Press SET. Read off multimeter display (e.g. 12,001 mA) and
enter this value in the user menu. Do this by scrolling one digit
to the right using and increasing the value of digit by 1 using
. Confirm with SET or abort entry with ESC.
7. Use or to select Adj. Point 3.
8. Press SET. Read off multimeter display (e.g. 18,401 mA) and
enter this value in the user menu. Do this by scrolling one digit
to the right using and increasing the value of digit by 1 using
. Confirm with SET or abort entry with ESC.
