TESTO Saveris Series User Manual

8 Technical data
103
Feature
Value
Accuracy ± 1 digit
Probe-specific
Resolution
0.1% / 0.1°C
Operating temperature
-30 to +50°C
Storage temperature
(including batteries)
-40 to +70°C
Protection class
IP 54
Measuring cycle
1 min to 24 h (15 minutes default)
Communication cycle
1 min to 24 h (15 minutes default)
Memory
10,000 readings / channel
Battery life 24 months (typical value, depending on the
WLAN infrastructure)
at +25°C, 15-minute measuring cycle, 15-
minute communication cycle
at -30°C and 15-minute measuring cycle, 15-
minute communication cycle (with
Energizer batteries 0515 0572)
Power supply
4 x AA AlMn batteries
Mains unit optional for temperatures below
-10°C please use Energizer batteries
0515 0572.
Dimensions
95 x 75 x 30.5 mm
Weight (including batteries)
Approx. 240 g
EN 12830-compliant
No
Door contact
No
Wall bracket
Included in the scope of delivery
External probes (digital) for testo Saveris 2 H2
Feature 0572 2162 0572 2163
6
0572 2164 0572 2165
Measurement
parameters
°C/°F °C/°F, %RH (+ °Ctd, g/m3)
Operating
temperature
-30 to +50 °C (86 to 122 °F)
Storage temperature
-30 to +60 °C (86 to 140 °F)
Measuring range
-30 to +50 °C
(86 to 122 °F)
-85 to +150 °C
7
(185 to 302 °F)
-30 to +50 °C (86 to 122 °F)/0 to
100% RH (non-condensing)
System accuracy
± 0.5 °C ±(0,25°C (0.5 °F)
+ 0,3% of m.v.)
± 0,5 °C (1 °F)
± 2,0 %rF for 0 to 90 %RH at 25 °C
(77 °F)
Resolution
0.1 °C
0,01
0.1 °C / 0.1 %RH
6
Pt100 accuracy class A.
7
Temperature range applies to the sensor tip as well as the cable of the Pt100 probe. In the case of the TUC
connector, the temperature range specified as „operating temperature” applies.

TESTO Saveris Series Specifications

General

Measurement Parameters	Temperature, Humidity, CO2, Pressure, Differential Pressure
Humidity Range	0 to 100 %RH
CO2 Range	0 to 5000 ppm
Communication	Ethernet, WiFi, USB
Data Storage	Internal memory
Alarm	Visual and audible alarms
Power Supply	Battery, Mains power
Software	Testo Saveris software
