Table 14-1. Data Flash Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
Advanced Charge
Algorithm
Cell Balancing
Config
0x4708 Bal Time/mAh Cell 2 U2 0 65535 361 s/mAh
Advanced Charge
Algorithm
Cell Balancing
Config
0x470A Min Start Balance Delta U1 0 255 3 mV
Advanced Charge
Algorithm
Cell Balancing
Config
0x470B Relax Balance Interval U4 0
429496729
5
18000 s
Advanced Charge
Algorithm
Cell Balancing
Config
0x470F Min Rsoc for Balancing U1 0 100 80 %
Gas Gauging Current Thresholds 0x46A1 Dsg Current Threshold I2 –32768 32767 100 mA
Gas Gauging Current Thresholds 0x46A3 Chg Current Threshold I2 –32768 32767 50 mA
Gas Gauging Current Thresholds 0x46A5 Quit Current I2 0 32767 10 mA
Gas Gauging Current Thresholds 0x46A7 Dsg Relax Time U1 0 255 1 s
Gas Gauging Current Thresholds 0x46A8 Chg Relax Time U1 0 255 60 s
Gas Gauging Standby 0x4618 StandbyCurrent I2 –32768 0 –10 mA
Gas Gauging Max Load 0x461A Max Load Current I2 –32768 0 –500 mA
Gas Gauging Max Load 0x461C Max Load Rsoc U1 0 100 50 %
Gas Gauging Design 0x4625 Design Capacity mAh I2 0 32767 4400 mAh
Gas Gauging Design 0x4627 Design Capacity cWh I2 0 32767 6336 cWh
Gas Gauging Design 0x4629 Design Voltage I2 0 32767 7200 mV
Gas Gauging Cycle 0x462B Cycle Count Percentage U1 0 100 90 %
Gas Gauging FD 0x4630 Set Voltage Threshold I2 0 5000 3000 mV
Gas Gauging FD 0x4632 Clear Voltage Threshold I2 0 5000 3100 mV
Gas Gauging FD 0x4634 Set % RSOC Threshold U1 0 100 0 %
Gas Gauging FD 0x4635 Clear % RSOC Threshold U1 0 100 5 %
Gas Gauging FC 0x4636 Set Voltage Threshold I2 0 5000 4200 mV
Gas Gauging FC 0x4638 Clear Voltage Threshold I2 0 5000 4100 mV
Gas Gauging FC 0x463A Set % RSOC Threshold U1 0 100 100 %
Gas Gauging FC 0x463B Clear % RSOC Threshold U1 0 100 95 %
Gas Gauging TD 0x463C Set Voltage Threshold I2 0 5000 3200 mV
Gas Gauging TD 0x463E Clear Voltage Threshold I2 0 5000 3300 mV
Gas Gauging TD 0x4640 Set % RSOC Threshold U1 0 100 6 %
Gas Gauging TD 0x4641 Clear % RSOC Threshold U1 0 100 8 %
Gas Gauging TC 0x4642 Set Voltage Threshold I2 0 5000 4200 mV
Gas Gauging TC 0x4644 Clear Voltage Threshold I2 0 5000 4100 mV
Gas Gauging TC 0x4646 Set % RSOC Threshold U1 0 100 100 %
Gas Gauging TC 0x4647 Clear % RSOC Threshold U1 0 100 95 %
Gas Gauging State 0x4206 Qmax Cell 1 I2 0 32767 4400 mAh
Gas Gauging State 0x4208 Qmax Cell 2 I2 0 32767 4400 mAh
Gas Gauging State 0x420A Qmax Pack I2 0 32767 4400 mAh
Gas Gauging State 0x420C Qmax Cycle Count U2 0 65535 0 —
Gas Gauging State 0x420E Update Status H1 0x0 0x0E 0x0 —
Gas Gauging State 0x420F Cell 1 Chg Voltage at EoC I2 0 32767 4200 mV
Gas Gauging State 0x4211 Cell 2 Chg Voltage at EoC I2 0 32767 4200 mV
Gas Gauging State 0x4213 Current at EoC I2 0 32767 250 mA
Gas Gauging State 0x4215 Avg I Last Run I2 –32768 32767 –2000 mA
Gas Gauging State 0x4217 Avg P Last Run I2 –32768 32767 –3022 cW
Gas Gauging State 0x4219 Delta Voltage I2 –32768 32767 0 mV
Gas Gauging State 0x421B Temp k I2 0 32767 100
0.1°C/256
cW
Gas Gauging State 0x421D Temp a I2 0 32767 1000 s
Gas Gauging State 0x421F Max Avg I Last Run I2 –32768 32767 –2000 mA
