Table 14-1. Data Flash Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
Gas Gauging State 0x4221 Max Avg P Last Run I2 –32768 32767 –3022 cW
Gas Gauging State 0x4240 Cycle Count U2 0 65535 0 —
Gas Gauging State 0x4720 SOH Temp k I2 0 32767 100
0.1°C/256
cW
Gas Gauging State 0x4722 SOH Temp a I2 0 32767 1000 s
Gas Gauging IT Cfg 0x4200 Design Resistance I2 1 32767 96 mΩ
Gas Gauging IT Cfg 0x4202 Pack Resistance I2 0 32767 30 mΩ
Gas Gauging IT Cfg 0x4204 System Resistance I2 0 32767 0 mΩ
Gas Gauging IT Cfg 0x458E Ra Filter U2 0 999 800 0.1%
Gas Gauging IT Cfg 0x4591 Ra Max Delta U1 0 255 15 %
Gas Gauging IT Cfg 0x4594 Resistance Parameter Filter U2 1 65535 65142 —
Gas Gauging IT Cfg 0x4596 Near EDV Ra Param Filter U2 1 65535 59220 —
Gas Gauging IT Cfg 0x45BC Qmax Delta U1 3 100 5 %
Gas Gauging IT Cfg 0x45BD Qmax Upper Bound U1 100 255 130 %
Gas Gauging IT Cfg 0x45BE Term Voltage I2 0 32767 6000 mV
Gas Gauging IT Cfg 0x45C0 Term V Hold Time U1 0 255 1 s
Gas Gauging IT Cfg 0x45C1 Term Voltage Delta I2 0 32767 300 mV
Gas Gauging IT Cfg 0x45C3 Term Min Cell V I2 0 32767 2800 mV
Gas Gauging IT Cfg 0x45CC Max Simulation Iterations U1 20 50 30 —
Gas Gauging IT Cfg 0x45DD Fast Scale Start SOC U1 0 100 10 %
Gas Gauging IT Cfg 0x45E6 Min Delta Voltage I2 –32768 32767 0 mV
Gas Gauging IT Cfg 0x464C Load Select U1 0 7 7 —
Gas Gauging IT Cfg 0x464D Load Mode U1 0 1 0 —
Gas Gauging IT Cfg 0x464E User Rate-mA I2 –9000 0 0 mA
Gas Gauging IT Cfg 0x4650 User Rate-cW I2 –32768 0 0 cW
Gas Gauging IT Cfg 0x4652 Reserve Cap-mAh I2 0 9000 0 mAh
Gas Gauging IT Cfg 0x4654 Reserve Cap-cWh I2 0 32000 0 cWh
Gas Gauging Smoothing 0x4656 Smooth Relax Time U2 1 32767 1000 s
Gas Gauging Condition Flag 0x4658 Max Error Limit U1 0 100 100 %
Gas Gauging Max Error 0x4727 Time Cycle Equivalent U1 1 255 12 2 h
Gas Gauging Max Error 0x4728 Cycle Delta U1 0 255 5 0.01%
Gas Gauging SoH 0x45E8 SoH Load Rate U1 0 255 50 0.1 Hr rate
Power Power 0x4605 Valid Update Voltage I2 0 32767 2800 mV
Power Shutdown 0x4607 Shutdown Voltage I2 0 32767 2300 mV
Power Shutdown 0x4609 Shutdown Time U1 0 255 10 s
Power Shutdown 0x460A Charger Present Threshold I2 0 32767 3000 mV
Power Sleep 0x460C Sleep Current I2 0 32767 10 mA
Power Sleep 0x460E Bus Timeout U1 0 255 5 s
Power Sleep 0x4613 Voltage Time U1 1 20 5 s
Power Sleep 0x4614 Current Time U1 1 60 20 s
Power Sleep 0x4615 Wake Comparator H1 0x0 0xFF 0x0 Hex
Power Ship 0x4616 FET Off Time U1 0 127 10 s
Power Ship 0x4617 Delay U1 0 254 20 s
Power Ship 0x461D Auto Ship Time U2 0 65535 1440 min
PF Status Device Status Data 0x42C0 Safety Alert A H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42C1 Safety Status A H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42C2 Safety Alert B H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42C3 Safety Status B H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42C4 Safety Alert C H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42C5 Safety Status C H1 0x0 0xFF 0x0 Hex
