Table 14-1. Data Flash Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
PF Status Device Status Data 0x42C6 Safety Alert D H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42C7 Safety Status D H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42C8 PF Alert A H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42C9 PF Status A H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42CA PF Alert B H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42CB PF Status B H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42CF PF Status D H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42D0 Operation Status A H2 0x0 0xFFFF 0x0 Hex
PF Status Device Status Data 0x42D2 Operation Status B H2 0x0 0xFFFF 0x0 Hex
PF Status Device Status Data 0x42D4 Temp Range H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42D5 Charging Status A H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42D6 Charging Status B H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42D7 Gauging Status H1 0x0 0xFF 0x0 Hex
PF Status Device Status Data 0x42D8 IT Status H2 0x0 0xFFFF 0x0 Hex
PF Status
Device Voltage
Data
0x42DA Cell 1 Voltage I2 –32768 32767 0 mV
PF Status
Device Voltage
Data
0x42DC Cell 2 Voltage I2 –32768 32767 0 mV
PF Status
Device Voltage
Data
0x42DE Battery Direct Voltage I2 –32768 32767 0 mV
PF Status
Device Voltage
Data
0x42E0 Pack Voltage I2 –32768 32767 0 mV
PF Status
Device Current
Data
0x42E2 Current I2 –32768 32767 0 mA
PF Status
Device Temperature
Data
0x42E4 Internal Temperature I2 –32768 32767 0 0.1 K
PF Status
Device Temperature
Data
0x42E6 External 1 Temperature I2 –32768 32767 0 0.1 K
PF Status
Device Temperature
Data
0x42E8 External 2 Temperature I2 –32768 32767 0 0.1 K
PF Status
Device Gauging
Data
0x42EA Cell 1 Dod0 I2 –32768 32767 0 —
PF Status
Device Gauging
Data
0x42EC Cell 2 Dod0 I2 –32768 32767 0 —
PF Status
Device Gauging
Data
0x42EE Passed Charge I2 –32768 32767 0 mAh
PF Status AFE Regs 0x42F0 AFE Interrupt Status H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42F1 AFE FET Status H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42F2 AFE RXIN H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42F3 AFE Latch Status H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42F4 AFE Interrupt Enable H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42F5 AFE FET Control H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42F6 AFE RXIEN H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42F7 AFE RLOUT H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42F8 AFE RHOUT H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42F9 AFE RHINT H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42FA AFE Cell Balance H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42FB AFE AD/CC Control H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42FC AFE ADC Mux H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42FD AFE LED Output H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42FE AFE State Control H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x42FF AFE LED/Wake Control H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x4300 AFE Protection Control H1 0x0 0xFF 0x0 Hex
www.ti.com Data Flash Summary
SLUUCO0 – APRIL 2022
Submit Document Feedback
BQ28Z610-R2 125
Copyright © 2022 Texas Instruments Incorporated
