Table 14-1. Data Flash Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
PF Status AFE Regs 0x4301 AFE OCD H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x4302 AFE SCC H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x4303 AFE SCD1 H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x4304 AFE SCD2 H1 0x0 0xFF 0x0 Hex
System Data Manufacturer Data 0x4041 Manufacturer Info Block A01 H1 0x0 0xFF 0x61 Hex
System Data Manufacturer Data 0x4042 Manufacturer Info Block A02 H1 0x0 0xFF 0x62 Hex
System Data Manufacturer Data 0x4043 Manufacturer Info Block A03 H1 0x0 0xFF 0x63 Hex
System Data Manufacturer Data 0x4044 Manufacturer Info Block A04 H1 0x0 0xFF 0x64 Hex
System Data Manufacturer Data 0x4045 Manufacturer Info Block A05 H1 0x0 0xFF 0x65 Hex
System Data Manufacturer Data 0x4046 Manufacturer Info Block A06 H1 0x0 0xFF 0x66 Hex
System Data Manufacturer Data 0x4047 Manufacturer Info Block A07 H1 0x0 0xFF 0x67 Hex
System Data Manufacturer Data 0x4048 Manufacturer Info Block A08 H1 0x0 0xFF 0x68 Hex
System Data Manufacturer Data 0x4049 Manufacturer Info Block A09 H1 0x0 0xFF 0x69 Hex
System Data Manufacturer Data 0x404A Manufacturer Info Block A10 H1 0x0 0xFF 0x6A Hex
System Data Manufacturer Data 0x404B Manufacturer Info Block A11 H1 0x0 0xFF 0x6B Hex
System Data Manufacturer Data 0x404C Manufacturer Info Block A12 H1 0x0 0xFF 0x6C Hex
System Data Manufacturer Data 0x404D Manufacturer Info Block A13 H1 0x0 0xFF 0x6D Hex
System Data Manufacturer Data 0x404E Manufacturer Info Block A14 H1 0x0 0xFF 0x6E Hex
System Data Manufacturer Data 0x404F Manufacturer Info Block A15 H1 0x0 0xFF 0x6F Hex
System Data Manufacturer Data 0x4050 Manufacturer Info Block A16 H1 0x0 0xFF 0x70 Hex
System Data Manufacturer Data 0x4051 Manufacturer Info Block A17 H1 0x0 0xFF 0x71 Hex
System Data Manufacturer Data 0x4052 Manufacturer Info Block A18 H1 0x0 0xFF 0x72 Hex
System Data Manufacturer Data 0x4053 Manufacturer Info Block A19 H1 0x0 0xFF 0x73 Hex
System Data Manufacturer Data 0x4054 Manufacturer Info Block A20 H1 0x0 0xFF 0x74 Hex
System Data Manufacturer Data 0x4055 Manufacturer Info Block A21 H1 0x0 0xFF 0x75 Hex
System Data Manufacturer Data 0x4056 Manufacturer Info Block A22 H1 0x0 0xFF 0x76 Hex
System Data Manufacturer Data 0x4057 Manufacturer Info Block A23 H1 0x0 0xFF 0x77 Hex
System Data Manufacturer Data 0x4058 Manufacturer Info Block A24 H1 0x0 0xFF 0x7A Hex
System Data Manufacturer Data 0x4059 Manufacturer Info Block A25 H1 0x0 0xFF 0x78 Hex
System Data Manufacturer Data 0x405A Manufacturer Info Block A26 H1 0x0 0xFF 0x79 Hex
System Data Manufacturer Data 0x405B Manufacturer Info Block A27 H1 0x0 0xFF 0x30 Hex
System Data Manufacturer Data 0x405C Manufacturer Info Block A28 H1 0x0 0xFF 0x31 Hex
System Data Manufacturer Data 0x405D Manufacturer Info Block A29 H1 0x0 0xFF 0x32 Hex
System Data Manufacturer Data 0x405E Manufacturer Info Block A30 H1 0x0 0xFF 0x33 Hex
System Data Manufacturer Data 0x405F Manufacturer Info Block A31 H1 0x0 0xFF 0x34 Hex
System Data Manufacturer Data 0x4060 Manufacturer Info Block A32 H1 0x0 0xFF 0x35 Hex
System Data Integrity 0x4061 Static DF Signature H2 0x0 0x7FFF 0x0 Hex
System Data Integrity 0x4063 Static Chem DF Signature H2 0x0 0x7FFF 0x6C98 Hex
System Data Integrity 0x4065 All DF Signature H2 0x0 0x7FFF 0x0 Hex
I2C Configuration Data 0x4067 Manufacture Date U2 0 65535 0 date
I2C Configuration Data 0x4069 Serial Number H2 0x0 0xFFFF 0x0001 Hex
I2C Configuration Data 0x406B Manufacturer Name S21 x x
Texas
Instruments
—
I2C Configuration Data 0x4080 Device Name S21 x x bq28z610 —
I2C Configuration Data 0x4095 Device Chemistry S5 x x LION —
Lifetimes Voltage 0x4280 Cell 1 Max Voltage I2 0 32767 0 mV
Lifetimes Voltage 0x4282 Cell 2 Max Voltage I2 0 32767 0 mV
Lifetimes Current 0x4284 Max Charge Current I2 0 32767 0 mA
Lifetimes Current 0x4286 Max Discharge Current I2 –32768 0 0 mA
Lifetimes Temperature 0x4288 Max Temp Cell I1 –128 127 –128 °C
Data Flash Summary www.ti.com
126 BQ28Z610-R2 SLUUCO0 – APRIL 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
