5.11.13. ENABLE TRANSFERS TO SRC 2 (GENERATOR)
The TSC 900 transfer switch controller contains “ENABLE TRANSFERS TO GEN” logic.
This feature is user programmable and allows 2 different functional settings which are
described below:
NO (DISABLED): The transfer switch will be inhibited from transferring to the
Generator position.
YES (ENABLED): The transfer switch will be permitted to transfer to the
Generator position.
5.11.14. ENABLE FAIL TO AUTO SYNC ALARM
When the ATS is ordered with a Closed Transition option (i.e. ATS Model Code Digit #13
“Operation Type” 3 or 4), and an external synchronizer is supplied, a fail to auto sync
alarm feature is available. When set to “YES” (i.e. enabled), it will post an alarm should
the sources fail to auto synchronize after expiry of the Fail to Auto Sync timer (i.e.
programmable per Section 5.16.2). The alarm will also activate the common TSC 900
"Transfer Fail" alarm output.
5.11.15. ENABLE HALT TRANSFER ON FAIL TO EXTERNAL SYNC
CHECK
The TSC 900 transfer switch controller contains a “HALT TRANSFER ON FAIL TO
EXTERNAL SYNC CHECK” logic selection feature. This feature is user programmable
and controls how the external automatic synchronizer initiate output is controlled.
NO (DISABLED): The Automatic Sync Initiate Output will stay energized to
continue an auto synchronizing operation irrespective if the “Fail to Auto Sync”
timer expires or not.
YES (ENABLED): The Automatic Sync Initiate Output will be de-energized upon
expiry of the “Fail to Auto Sync” time delay setting to halt further auto sync
operation.
5.11.16. ENABLE CLOSED TRANSITION TRANSFER (CTTS MODEL 3 &
4)
When the ATS is ordered with a Closed Transition Transfer option (i.e. ATS Model Code
Digit #13 “Operation Type” 3 or 4) the ATS can be selected for closed transition
operation. When the option is set to YES, the ATS will operate in a Closed Transition
transfer sequence dependent upon if both sources are available and the specific setting
of the GHC Home Page or via external control switch (if fitted). Three operation mode
settings are provided as follows:
