4. OPERATING INSTRUCTIONS
The GHC software provides the TSC 900 control and monitoring information which is visible on the
GHC Display or remote PC. All screen page navigation is controlled by a touchscreen display using a
“finger swipe” motion and/or button press actions. The GHC has pre-programmed display pages which
are selected manually using the touchscreen display. The following screen naming conventions will be
used throughout the document when describing the GHC software screens:
4.1. GHC SCREEN PAGE NAVIGATION
Two methods are available to manually select a desired screen page as follows:
1) Navigation Menu Bar –a finger swipe motion can be used (swipe left or right) on the
menu bar itself.
2) Home Short-Cut Button - To directly access the Home Page from any screen press
the following ICON:
4.2. HELP INFORMATION
Help Information screens are available whenever a question mark Icon is displayed. Press the
Icon to open up further information on the specific item.
