5.9.5. PROGRAMMABLE OUTPUT FUNCTION LIST
The following output functions can be mapped to any programmable output. Note:
outputs can be programmed multiple times to provide additional output contacts of same
type.
TagName TagDescription
alm.any ATS Common Fail Alarm
alm.gen.failtorun.1 Gen 1 Failed While Running
alm.gen.failtorun.2 Gen 2 Failed While Running
alm.gen.muststart.1 Gen 1 Standby Source Failed to Start
alm.gen.muststart.2 Gen 2 Standby Source Failed to Start
alm.onsrc.1 Src 1 Fail to Transfer Common Alarm
alm.onsrc.2 Src 2 Fail to Transfer Common Alarm
alm.xfr.detect.1 Load on Src 1 Limit Sw/Aux Contact Failure
alm.xfr.detect.2 Load on Src 2 Limit Sw/Aux Contact Failure
alm.xfr.fail ATS Fail to Transfer Common Alarm
alm.xfr.mech.1 Src 1 Fail to Open/Close Alarm
alm.xfr.mech.2 Src 2 Fail to Open/Close Alarm
alm.xfr.sync Fail to Drift Sync Timeout
alm.xfr.sync.ext Fail to Externally Auto Sync Timeout
alm.xfr.trip.1 Loss of Load Voltage - Src 1 Contacts Open
alm.xfr.trip.2 Loss of Load Voltage - Src 2 Contacts Open
alm.xfr.unload.1 Src 1 Fail to Unload
alm.xfr.unload.2 Src 2 Fail to Unload
ctl.auto Controller in Auto
ctl.breaker.1.trip SRC 1 Trip Breaker
ctl.breaker.2.trip SRC 2 Trip Breaker
ctl.discon.req.a Service Disconnect Mode Activated
ctl.discon.req.b Disconnect Request (GHC)
ctl.disconnected Service Entrance Disc. Init
ctl.goto.discon Disconnect All Sources
ctl.goto.man De-Energize All Sources
ctl.halted System Halted
ctl.ldc Load Disconnect Contact (Pre/Post Transfer)
ctl.ldc.post Load Post-Disconnect
ctl.ldc.pre Load Pre-Disconnect
ctl.manual Control Manual
ctl.off Control Off
ctl.off.req.a Non-Auto Off Request (Remote)
ctl.off.req.b Non-Auto Off Request (GHC)
ctl.onsrc Load on Either Source
ctl.onsrc.1 Load on SRC 1
ctl.onsrc.2 Load on SRC 2
ctl.outputs.o01 User Def Output 1
ctl.outputs.o02 User Def Output 2
