THOMSON TSC 900 User Manual

TSC 900 TRANSFER SWITCH CONTROLLER
PM 151 REV 5 16/04/19 Thomson Power Systems
67
5.8.5. PROGRAMMABLE INPUT FUNCTION LIST
The following input functions can be mapped to any programmable input. Note: inputs
can be programmed only once (i.e. same input type cannot be utilized on multiple
programmable inputs).
TagName TagDescription
ctl.discon.req.a Service Disconnect Mode Activated
ctl.inputs.i01 User Def Input 1
ctl.inputs.i02 User Def Input 2
ctl.inputs.i03 User Def Input 3
ctl.inputs.i04 User Def Input 4
ctl.inputs.i05 User Def Input 5
ctl.inputs.i06 User Def Input 6
ctl.inputs.i07 User Def Input 7
ctl.inputs.i08 User Def Input 8
ctl.inputs.i09 User Def Input 9
ctl.inputs.i10 User Def Input 10
ctl.inputs.i11 User Def Input 11
ctl.inputs.i12 User Def Input 12
ctl.inputs.i13 User Def Input 13
ctl.inputs.i14 User Def Input 14
ctl.inputs.i15 User Def Input 15
ctl.inputs.i16 User Def Input 16
ctl.man.req.a Transfer Control in Manual
ctl.off.req.a Non-Auto Off Request (Remote)
ctl.reset.req Reset Alarm Request
ctl.rtn.req.a Manual Return Request (Remote)
ctl.start.1.remote.a Off Load Test Request (GEN 1)
ctl.start.2.remote.a Off Load Test Request (Remote)
ctl.stdby.req Standby Request
ctl.sync.ext.fail Ext. Sync Check Failed
ctl.synced.ext Ext. Sync Check Permitted
ctl.unfail.req.a Unfail Request (Remote)
ctl.unhalt.req.a Unhalt Request (Remote)
ctl.unloaded.1 SRC 1 Unload Permitted
ctl.unloaded.2 SRC 2 Unload Permitted
