THOMSON TSC 900 User Manual

TSC 900 TRANSFER SWITCH CONTROLLER
PM 151 REV 5 16/04/19 Thomson Power Systems
68
TagName TagDescription
ilk.xfr.closed.inhibit Closed Transition Mode Inhibit
ilk.xfr.closed.inhibit.prot Closed Transition Inhibit Prot
ilk.xfr.closed.permit Closed Transition Mode Permit
ilk.xfr.inphase.inhibit In-Phase Transfer Inhibit
ilk.xfr.inphase.permit In-Phase Transfer Permit
ilk.xfr.ndtbypass.inhibit NDT Bypass Inhibit
ilk.xfr.ndtbypass.permit NDT Bypass Permit
ilk.xfr.parallel.inhibit Enable Extended Parallel Transfer Inhibit (CTTS Model 4)
ilk.xfr.parallel.permit Enable Extended Parallel Transfer Permit (CTTS Model 4)
ilk.xfr.revert.inhibit Revert to Open Transition Inhibited
ilk.xfr.revert.permit Revert to Open Transition Permited
ilk.xfr.soft.inhibit Soft Load ATS Mode Inhibit
ilk.xfr.soft.permit Soft Load ATS Mode Permit
ilk.xfr.tosrc.1.inhibit Inhibit Transfer to SRC 1
ilk.xfr.tosrc.1.permit Permit Transfer to SRC 1
ilk.xfr.tosrc.2.inhibit Inhibit Transfer to SRC 2
ilk.xfr.tosrc.2.permit Permit Transfer to SRC 2
pfs.pause Pause Automatic Source Alternation
pfs.req.1 SRC 1 Prime Unit Selected
pfs.req.2 SRC 2 Prime Unit Selected
pfs.trouble.1 SRC 1 Alarm Input
pfs.trouble.2 SRC 2 Alarm Input
test.req.remote.a Remote Test Request
tip.switch.opened.1 SRC 1 Power Switching Device Opened
tip.switch.opened.2 SRC 2 Power Switching Device Opened
tip.switch.tripped.1 SRC 1 Power Switch. Device Tripped
tip.switch.tripped.2 SRC 2 Power Switch. Device Tripped
tmr.clr.remote.a Clear Timers Request (Remote)
