TSC 900 TRANSFER SWITCH CONTROLLER
PM 151 REV 5 16/04/19 Thomson Power Systems
5.8.3. TS 880 (ICS) STANDARD/SERVICE ENTRANCE INPUT DEFAULTS:
5.8.4. TS 880 (ICS) CLOSED TRANSITION INPUT DEFAULTS:
Inputs GHC Descriptions SCU TAG Names
IP01
Remote Test - Utility Power Fail Simulate
test.req.remote.a
Remote Alarm Reset
ctl.reset.req
Service Disconnect Mode Activated
ctl.discon.req.a
Utility Power Switching Device (USD) Tripped
tip.switch.tripped.1
Transfer Control in Manual (External Control
Switch)
ctl.man.req.a
IP07
Not mapped
IP08
Utility Power Switching Device (USD) Open*
tip.switch.opened.1
Generator Power Switching Device (GSD) Open*
tip.switch.opened.2
IP10
Not mapped
IP11
Not mapped
IP12
Not mapped
IP13
Not mapped
IP14
Not mapped
IP15
Closed Transition Extended Parallel
ilk.xfr.tosrc.1.inhibit
IP16 Inhibit Transfer to Generator (Source 2) ilk.xfr.tosrc.2.inhibit
Inputs GHC Descriptions SCU TAG Names
IP01
Remote Test - Utility Power Fail Simulate
test.req.remote.a
Remote Alarm Reset
ctl.reset.req
Service Disconnect Mode Activated
ctl.discon.req.a
Utility Power Switching Device (USD) Tripped
tip.switch.tripped.1
IP05
Closed Transition Extended Parallel
ilk.xfr.parallel.permit
IP06
Transfer Control in Manual
ctl.man.req.a
Transfer Control in Closed Transition Mode
ilk.xfr.closed.permit
Utility Power Switching Device (USD) Open*
tip.switch.opened.1
Generator Power Switching Device (GSD) Open*
tip.switch.opened.2
Closed Transition Inhibit (Utility Protection Relay
Trip)
ilk.xfr.closed.inhibit.prot
IP11
Gen (Source 2) Unloaded
ctl.unloaded.2
IP12
Utility (Source 1) Unloaded
ctl.unloaded.1
IP13
In-Sync Transfer Permit
ctl.synced.ext
IP14
Closed Transition Soft-Load
ilk.xfr.soft.permit
IP15
Inhibit Transfer to Utility (Source 1)
ilk.xfr.tosrc.1.inhibit
IP16 Inhibit Transfer to Generator (Source 2) ilk.xfr.tosrc.2.inhibit
