5.9. PROGRAMMABLE OUTPUT MAPPING
All 8 Programmable outputs can be mapped to a number of different parameters to suit the
application. The TSC 900 is provided with factory programmed default settings based upon the
ATS configuration. Refer to the following sections for specific default program tables.
5.9.1. TS 870 STANDARD/SERVICE ENTRANCE OUTPUT DEFAULTS:
5.9.2. TS 870 DUAL SOURCE OUTPUT DEFAULTS:
5.9.3. TS 880 (ICS) STANDARD/SERVICE ENTRANCE OUTPUT
DEFAULTS:
5.9.4. TS 880 (ICS) CLOSED TRANSITION OUTPUT DEFAULTS:
Outputs GHC Descriptions SCU TAG Names
OP01
Load on Source 1
ctl.onsrc.1
OP02
Load on Source 1
ctl.onsrc.1
OP03
Load on Source 2
ctl.onsrc.2
OP04
Load on Source 2
ctl.onsrc.2
OP05
Load Disconnect Contact (LDC) (Pre/Post
Transfer Output)
ctl.ldc
OP06
Transfer Fail Alarm
alm.any
OP07
ATS Not in Auto
!ctl.auto
OP08
Source 1 Power Fail (UPF) trp.src.1.any
Outputs GHC Descriptions SCU TAG Names
OP01
Load on Utility
ctl.onsrc.1
OP02
Load on Utility
ctl.onsrc.1
OP03
Load on Generator
ctl.onsrc.2
OP04
Load on Generator
ctl.onsrc.2
OP05
Load Disconnect Contact (LDC) (Pre/Post
Transfer Output)
ctl.ldc
OP06
Transfer Fail Alarm
alm.any
OP07
ATS Not in Auto
!ctl.auto
OP08
Utility Power Fail (UPF) trp.src.1.any
Outputs GHC Descriptions SCU TAG Names
OP01
Load on Utility
ctl.onsrc.1
OP02
Load on Utility
ctl.onsrc.1
OP03
Load on Generator
ctl.onsrc.2
OP04
Load on Generator
alm.any
OP05
Load Disconnect Contact (LDC) (Pre/Post
Transfer Output)
ctl.ldc
OP06
Not Mapped
OP07
Not Mapped
OP08
Not Mapped
Outputs GHC Descriptions SCU TAG Names
OP01
Load on Utility
ctl.onsrc.1
OP02
Load on Utility
ctl.onsrc.1
OP03
Load on Generator
ctl.onsrc.2
OP04
Transfer Fail Alarm
alm.any
OP05
Load Disconnect Contact (LDC) (Pre/Post
Transfer Output)
ctl.ldc
OP06
Automatic Sync Initiate
ctl.sync.ext
OP07
Generator (Source 2) Unload
ctl.unload.2
OP08
Utility (Source 1) Unload clt.unload.1
