THOMSON TSC 900 User Manual

TSC 900 TRANSFER SWITCH CONTROLLER
PM 151 REV 5 16/04/19 Thomson Power Systems
100
6. FACTORY DEFAULT PROGRAMMING
Function Tag Range
Factory
Default
Value
Basic
Advanced
Factory
System Phases sys.phases 1, 3 3 Ph
x x x
System Voltage sys.volt
0 - 25000 277/480 V
x x x
System Frequency sys.freq 50/60 Hz 60 Hz
x x x
Phase Rotation Reversed sys.rot.reverse YES/NO NO
x x x
Rated GEN Power sys.gen.pwr 0-5000 kW 2500 KW
x x
CT Ratio sys.ct.scale 1 - 1000
1
x x
PT Ratio sys.pt.scale 1 - 500
1
x x
Load Name sys.desc.load n/a Load
x x
SRC 1 Name sys.desc.src.1 n/a Utility
x x
SRC 2 Name sys.desc.src.2 n/a Gen
x x
Application Model sys.model.application
x x
Switch Operation sys.model.operation
x x
Switch Model sys.model.switch
x x
SRC 2 (GEN) Commit to Transfer
opt.ctl.commit
YES/NO NO
x x
Enable Load Shed on Under Frequency
opt.shed.freq
YES/NO YES
x x
Enable Load Shed on Over Power
opt.shed.power
YES/NO YES
x x
Halt Operation on Phase Reversal
opt.ctl.haltonreverse
YES/NO YES
x x
Manual SRC 1 (Utility) Retransfer Control
opt.ctl.manrtn
YES/NO NO
x x
Force Transfer
opt.ctl.xfronfail
YES/NO YES
x x
GHC Sleep Mode Timeout
opt.disp.sleep.dly
0-6000 sec 300 sec
x x
Load Power Metering
opt.lpm
YES/NO NO
x x
Modbus RTU
opt.modbus.rtu
YES/NO YES
x x
Modbus TCP/IP
opt.modbus.tcpip
YES/NO NO
x x
Enable Security Bypass
opt.security.mode
YES/NO YES
x x
Enable Neutral Delay Bypass
opt.xfr.ndtbypass
YES/NO NO
x x
Enable Transfers to SRC 1 (Utility)
opt.xfr.tosrc.1
YES/NO YES
x x
Enable Transfers to SRC 2 (Generator)
opt.xfr.tosrc.2
YES/NO YES
x x
Enable Fail to Auto Sync Alarm (CTTS Model 3/4)
opt.alm.sync.ext
YES/NO NO
x x
Enable Halt Transfer on Fail to Ext Sync Check (CTTS Model 3/4)
opt.xfr.sync.ext.haltonfail
YES/NO NO
x x
Enable Closed Transition Transfer (CTTS Model 3/4)
1
opt.xfr.closed
YES/NO NO
x x
Revert to Open Transition
1
opt.xfr.revert
YES/NO YES
x x
Enable Fail to Unload Alarm (CTTS Model 4)
opt.alm.unload
YES/NO YES
x x
Enable Extended Parallel Transfer (CTTS Model 4)
opt.xfr.parallel
YES/NO NO
x x
Enable Soft Load Transfer (CTTS Model 4)
opt.xfr.soft
YES/NO NO
x x
Enable Start of Multiple GENs When Resuming from Standby
2
opt.ctl.stdby.multistart YES/NO NO
x x
Preferred Source Alternation Interval
2
opt.pfs.alt.interval
1-672 HRS 1 HR
x x
Trip Utility (SRC 1) When Closed Transition Inhibit Activated
1
opt.xfr.closed.tripaction
YES/NO YES
x x
Current Metering
opt.ct
YES/NO NO
x
Advanced Power Metering
opt.apm
YES/NO NO
x
Enable Open Transition In-Sync Transfer (ATS Operation Type X)
opt.xfr.inphase
YES/NO YES
x
Read Only
Read Only
Read Only
System Configuration
Option Settings
