THOMSON TSC 900 User Manual

TSC 900 TRANSFER SWITCH CONTROLLER
PM 151 REV 5 16/04/19 Thomson Power Systems
101
Function Tag Range
Factory
Default
Value
Basic
Advanced
Factory
UTIL Return Delay
3
dly.util.rtn 0-1800 sec 300 sec
x x x
Gen Cool Down Delay
dly.gen.cool
0-3600 sec 300 sec
x x x
Gen Start Delay
3
dly.gen.start
0-60 sec 3 sec
x x x
Gen Warm Up Delay
dly.gen.warm
0-3600 sec 2 sec
x x x
Transfer Neutral Delay
dly.xfr.neut
0-120 sec 3 sec
x x x
Transfer Pre-Delay (LDC)
dly.xfr.pre
0-120 sec 0 sec
x x x
Transfer Post Delay (LDC)
dly.xfr.post
0-120 sec 3 sec
x x x
SRC 2 (Gen) Commit to Transfer Delay
dly.commit
0-600 sec 300 sec
x x
Transfer Fail Delay
dly.xfr.fail
0-120 sec 30 sec
x x
Transfer Max Error Condition Delay
dly.xfr.swfail
2-30 sec 5 sec
x x
Gen (SRC 2) Failed to Start Delay stp.alm.gen.muststart.delay 0-300 sec 60 sec
x x
Disconnection Resume Time
dly.discon.resume
0-10 sec 5.0 sec
x
Utility (SRC 1) Trip Retry ON/OFF Pulse Time
1
dly.coil.brksrc.pulse.1
0.05 -5 sec 0.10 sec
x
Gen (SRC2) Trip Retry ON/OFF Pulse Time
1
dly.coil.brksrc.pulse.2
0.05 -5 sec 0.10 sec
x
Utility (SRC 1) Trip Retry Duration Timer
1
dly.coil.brksrc.retry.1
0.05 -30 sec 0.60 sec
x
Gen (SRC 2) Trip Retry Duration Timer
1
dly.coil.brksrc.retry.2
0.05 -30 sec 0.60 sec
x
Utility (SRC 1) Close Retry ON/OFF Pulse Time
1
dly.coil.tosrc.pulse.1
0.05 -5 sec 0.10 sec
x
Gen (SRC2) Close Retry ON/OFF Pulse Time
1
dly.coil.tosrc.pulse.2
0.05 -5 sec 0.10 sec
x
Utility (SRC 1) Close Retry Duration Timer
1
dly.coil.tosrc.retry.1
0.05 -30 sec 0.60 sec
x
Gen (SRC 2) Close Retry Duration Timer
1
dly.coil.tosrc.retry.2
0.05 -30 sec 0.60 sec
x
Timer Guard Delay
1
dly.xfr.guard
0.1-10 sec 0.2 sec
x
Find Neutral Delay
4
dly.xfr.find
0-10 sec 1.0 sec
x
Return To Preferred Source Delay
2
dly.rtn
0-1800 sec 300 sec
x x x
Wait For Preferred Source Delay
2
dly.stdby.pref 0-300 sec 60 sec
x x
Transfer From Preferred Source Delay
2
dly.dprt 0-60 sec 5 sec
x x x
1
Setting applicable only to ATS Operation Type 1, X, 3, 4
2
Setting only visible in dual source configurations
3
Time delays not visible in dual source applications
4
Find Neutral Delay S-Style =1.0sec, T-Style= 1.5 sec
Delay Settings
