TSC 900 TRANSFER SWITCH CONTROLLER

PM 151 REV 5 16/04/19 Thomson Power Systems

102

Function Tag Range

Factory

Default

Value

Basic

Advanced

Factory

SRC 1 (Utility) Under Voltage Delay

stp.vsrc.1.volt.undr.delay

0-10 sec 1 sec

x x

SRC 1 (Utility) Under Voltage Drop Out

stp.vsrc.1.volt.undr.drop

70-95% 85%

x x x

SRC 1 (Utility) Under Voltage Pick Up

stp.vsrc.1.volt.undr.pick

75-100% 90%

x x x

SRC 1 (Utility) Over Voltage Delay

stp.vsrc.1.volt.over.delay

0-10 sec 1 sec

x x

SRC 1 (Utility) Over Voltage Drop Out

stp.vsrc.1.volt.over.drop

100-130% 110%

x x

SRC 1 (Utility) Over Voltage Pick Up

stp.vsrc.1.volt.over.pick

100-130% 115%

x x

SRC 1 (Utility) Phase Unbalance Latch

stp.vsrc.1.volt.unbal.latch

YES/NO NO

x x

SRC 1 (Utility) Phase Unbalance Delay

stp.vsrc.1.volt.unbal.delay

0-30 sec 5 sec

x x

SRC 1 (Utility) Phase Unbalance Drop Out

stp.vsrc.1.volt.unbal.drop

0-100% 3%

x x

SRC 1 (Utility) Phase Unbalance Pick Up

stp.vsrc.1.volt.unbal.pick

0-100% 5%

x x

SRC 1 (Utility) Under Frequency Delay

stp.vsrc.1.freq.undr.delay

0-10 sec 1 sec

x x

SRC 1 (Utility) Under Frequency Drop Out

stp.vsrc.1.freq.undr.drop

70-99% 85%

x x

SRC 1 (Utility) Under Frequency Pick Up

stp.vsrc.1.freq.undr.pick

70-99% 90%

x x

SRC 1 (Utility) Over Frequency Delay

stp.vsrc.1.freq.over.delay 0-10 sec 1 sec

x x

SRC 1 (Utility) Over Frequency Drop Out

stp.vsrc.1.freq.over.drop

100-130% 110%

x x

SRC 1 (Utility) Over Frequency Pick Up

stp.vsrc.1.freq.over.pick

100-130% 115%

x x

SRC 1 (Utility) Voltage Rotation Reverse Delay

stp.vsrc.1.volt.reverse.delay

0-30 sec 2 sec

SRC 1 (Utility) Voltage Rotation Reverse Drop Out

stp.vsrc.1.volt.reverse.drop

0-100% 64%

SRC 1 (Utility) Voltage Rotation Reverse Pick Up

stp.vsrc.1.volt.reverse.pick

0-100% 68%

SRC 1 (Utility) Voltage Source Blackout Delay

stp.vsrc.volt.black.delay

0-10 sec 0 sec

SRC 1 (Utility) Voltage Source Blackout Drop Out

stp.vsrc.volt.black.drop

0-100% 20%

SRC 1 (Utility) Voltage Source Blackout Pick Up

stp.vsrc.volt.black.pick

0-100% 30%

SRC 2 (Gen) Under Voltage Delay

stp.vsrc.2.volt.undr.delay

0-10 sec 3 sec

x x

SRC 2 (Gen) Under Voltage Drop Out

stp.vsrc.2.volt.undr.drop

70-95% 85%

x x x

SRC 2 (Gen) Under Voltage Pick Up

stp.vsrc.2.volt.undr.pick

75-100% 90%

x x x

SRC 2 (Gen) Over Voltage Delay

stp.vsrc.2.volt.over.delay

0-10 sec 3 sec

x x

SRC 2 (Gen) Over Voltage Drop Out

stp.vsrc.2.volt.over.drop

100-130% 110%

x x

SRC 2 (Gen) Over Voltage Pick Up

stp.vsrc.2.volt.over.pick

100-130% 115%

x x

SRC 2 (Gen) Phase Unbalance Latch

stp.vsrc.2.volt.unbal.latch

YES/NO NO

x x

SRC 2 (Gen) Phase Unbalance Delay

stp.vsrc.2.volt.unbal.delay

0-30 sec 5 sec

x x

SRC 2 (Gen) Phase Unbalance Drop Out

stp.vsrc.2.volt.unbal.drop

0-100% 3%

x x

SRC 2 (Gen) Phase Unbalance Pick Up

stp.vsrc.2.volt.unbal.pick

0-100% 5%

x x

SRC 2 (Gen) Under Frequency Delay

stp.vsrc.2.freq.undr.delay

0-10 sec 5 sec

x x

SRC 2 (Gen) Under Frequency Drop Out

stp.vsrc.2.freq.undr.drop

70-99% 85%

x x

SRC 2 (Gen)Under Frequency Pick Up

stp.vsrc.2.freq.undr.pick

70-99% 90%

x x

SRC 2 (Gen) Over Frequency Delay

stp.vsrc.2.freq.over.delay

0-10 sec 3 sec

x x

SRC 2 (Gen) Over Frequency Drop Out

stp.vsrc.2.freq.over.drop

100-130% 110%

x x

SRC 2 (Gen) Over Frequency Pick Up

stp.vsrc.2.freq.over.pick

100-130% 115%

x x

SRC 2 (Gen) Voltage Rotation Reverse Delay

stp.vsrc.2.volt.reverse.delay

0-30 sec 2 sec

SRC 2 (Gen) Voltage Rotation Reverse Drop Out

stp.vsrc.2.volt.reverse.drop

0-100% 64%

SRC 2 (Gen) Voltage Rotation Reverse Pick Up stp.vsrc.2.volt.reverse.pick 0-100% 68%

Source 2 (Generator) Set Points

Source 1 (Utility) Set Points
