THOMSON TSC 900 User Manual

TSC 900 TRANSFER SWITCH CONTROLLER
PM 151 REV 5 16/04/19 Thomson Power Systems
74
TagName TagDescription
ctl.outputs.o03 User Def Output 3
ctl.outputs.o04 User Def Output 4
ctl.outputs.o05 User Def Output 5
ctl.outputs.o06 User Def Output 6
ctl.outputs.o07 User Def Output 7
ctl.outputs.o08 User Def Output 8
ctl.reset.req Reset Alarm Request
ctl.rtn.req.a Manual Return Request (Remote)
ctl.rtn.req.b Manual Return Request (GHC)
ctl.shed Load is Shed
ctl.src.1.avail SRC 1 Available
ctl.src.2.avail SRC 2 Available
ctl.start.2.remote.a Off Load Test Request (Remote)
ctl.start.2.remote.b Off Load Test Request (GHC)
ctl.stdby.req Standby Request
ctl.sync.ext Auto Sync Initiate
ctl.sync.ext.fail Ext. Sync Check Failed
ctl.synced.ext Ext. Sync Check Permitted
ctl.transferring Control Transferring
ctl.underway Transfer Underway
ctl.unload.1 SRC 1 Unload Initiate
ctl.unload.2 SRC 2 Unload Initiate
ctl.unloaded.1 SRC 1 Unload Permitted
ctl.unloaded.2 SRC 2 Unload Permitted
ctl.waiting Wait for Sync
ena.xfr.closed Closed Transfer (Model 3/4)
ena.xfr.inphase In-Phase Transfer (Model X)
ena.xfr.ndtbypass Neutral delay timer bypass
ena.xfr.parallel Enable Extended Parallel Transfer (CTTS Model 4)
ena.xfr.revert Revert to Open Transfer
ena.xfr.soft Enable Soft Load Transfer (CTTS Model 4)
ena.xfr.tosrc.1 Enable Transfer to SRC 1
ena.xfr.tosrc.2 Enable Transfer to SRC 2
exr.active Exercise Active
exr.active.offload Exercise Active Offload
exr.active.onload Exercise Active Onload
exr.req.local Local Exercise Request
exr.req.remote.a Terminal Exercise Request
exr.req.remote.man Manual Exercise Request (GHC)
ilk.xfr.tosrc.1.inhibit Inhibit Transfer to SRC 1
