THOMSON TSC 900 User Manual

TSC 900 TRANSFER SWITCH CONTROLLER
PM 151 REV 5 16/04/19 Thomson Power Systems
75
TagName TagDescription
ilk.xfr.tosrc.1.permit Permit Transfer to SRC 1
ilk.xfr.tosrc.2.permit Permit Transfer to SRC 2
sync.xfr.trigger Sources are In-Phase
test.active Test Active
test.active.local Local Test Active
test.active.remote Remote Test Active
test.req.remote.a Remote Test Request
test.req.remote.b GHC Test Request
tip.switch.onsrc.1 ATS on SRC 1
tip.switch.onsrc.2 ATS on SRC 2
tip.switch.opened.1 SRC 1 Power Switching Device Opened
tip.switch.opened.2 SRC 2 Power Switching Device Opened
tip.switch.tripped.1 SRC 1 Power Switch. Device Tripped
tip.switch.tripped.2 SRC 2 Power Switch. Device Tripped
tmr.rtn Return to Preferred Source
tmr.stdby.pref Wait for Preferred Source
tmr.util.rtn UTIL Return
top.start.2 Engine Start Request SRC 2
top.switch.bksrc.1 Breaker 1 to output
top.switch.bksrc.2 Breaker 2 to output
top.switch.tosrc.1 SRC 1 to output
top.switch.tosrc.2 SRC 2 to output
trp.load.volt.black Load Blackout Voltage
trp.shed.freq Load Shed Freq Active
trp.shed.power Load Shed kW Active
trp.src.1.any SRC 1 Power Fail
trp.src.1.freq.over SRC 1 Overfrequency
trp.src.1.freq.undr SRC 1 Underfrequency
trp.src.1.volt.over SRC 1 Overvoltage
trp.src.1.volt.reverse SRC 1 Voltage Rotation Reversed
trp.src.1.volt.unbal SRC 1 Unbalancedvoltage
trp.src.1.volt.undr SRC 1 Undervoltage
trp.src.2.any SRC 2 Power Fail
trp.src.2.freq.over SRC 2 Overfrequency
trp.src.2.freq.undr SRC 2 Underfrequency
trp.src.2.volt.over SRC 2 Overvoltage
trp.src.2.volt.reverse SRC 2 Voltage Rotation Reversed
trp.src.2.volt.unbal SRC 2 Unbalancedvoltage
trp.src.2.volt.undr SRC 2 Undervoltage
trp.sync.any Synchronization Out-of-Spec

THOMSON TSC 900 Specifications

General

Brand	THOMSON
Model	TSC 900
Category	Controller
Language	English
