Set the LTC Level
If you set your UltraSync ONE up to output LTC (timecode) via the LTC port, you
need to set the LTC level. This is a voltage for the LTC signal, and it has to match
the voltage that is supported by the external device that will receive the LTC signal.
To find out the voltage your external device requires, please refer to the
manufacturer's instructions. When you have that information, you can set the LTC
level.
Note: If you are using your UltraSync ONE to output LTC via the SYNC
port, you will need to set the level for the SYNC port (see Set the SYNC
Output on page 76).
To set the LTC Level:
1. Make sure your UltraSync ONE is switched on (see Switch UltraSync ONE On
and Off on page 11).
2. Press the Select button.
3. Use the Up and Down buttons to scroll to the System Settings option.
4. Press the Select button.
5. Use the Up and Down buttons to scroll to the LTC Output Level option.
6. Press the Select button.
7. Choose the LTC output that matches the LTC input voltage that is required by
your external device:
l Std Level - 3Vpp signal
l MIC Level - 70mVpp signal
l Low Level - 600mVpp signal
8. Press the Select button to confirm.
78 UltraSync ONE User Guide
