Topcon DL-501 User Manual

47
12. HEIGHT DIFFERENCE MEASUREMENT
4. Press [NEW].
5. Set the following data items.
(1) Route ID
(2) Memo
(3) Start bench mark ID
(4) Start bench mark elevation
(5) End bench mark ID
(6) End bench mark elevation
(7) Double-run setting
(8) Measurement order
(9) Measurement procedure
(10) Ht resolution
(11) Distance resolution
(12) Rh range
(13) dH range
(14) Upper tolerance (distance)
(15) Lower tolerance (distance)
(16) Upper tolerance (ht)
(17) Lower tolerance (ht)
(18) Distance difference between backsight
and foresight
(19) Total distance difference between
backsight and foresight
• Press [READ] to read in route data when
setting
Start bench mark ID and End bench
mark ID.
 "12.3 Setting-Out Measurement
PROCEDURE Reading in recorded
known point data"
OK
Route setting
:R1
DETAIL
NEWLIST
OK
Start bench mark id
:B1
Start bench mark elev.
: 150.00000m
READ
1
OK
End bench mark id
:B2
End bench mark elev.
: 165.00000m
READ
1
OK
Line :Go
Order :1
Meas.Proc:BFFB
OK
Ht reso. :0.1mmGo
Dist reso.:0.001m
Rh range : 0.50mm
dH range : 1.00mm
OK
Route id
: Route-001
Memo
:
:
A
OK
Upper dist :40.000 mo
Lower dist: 3.000 m
Upper Rh : 2.80000m
Lower Rh : 0.20000m
1
