12. HEIGHT DIFFERENCE MEASUREMENT
•Press [OK] in the screen shown at right to
record results and return to the previous
screen.
Measurements of subsequent IS points can
be performed from this screen.
Press {ESC} to exit IS measurement.
• When height difference measurement in the
first section is complete, press [S-O] in the
second page to perform setting-out.
16. Set up the DL in the center of the next section.
17. Repeat steps 8 to 15 to measure the
subsequent sections. The foresight for the
previous section becomes the backsight for
the current section.
•Press [FIXEDP] in the screen of step 15 to
set up a fixed point. Input a temperature and
memo and press [OK] to proceed the next
screen.
Press [END] then [YES] in the screen shown
at right to end height difference measurement
and return to <Height dif. meas menu>.
18. Check the results for the final section.
Press [END] in the results screen for the final
section.
19. Set temperature and enter a memo.
Press [OK] to record results and end height
difference measurement.
<Height dif. meas menu> is restored.
IS Go
Route01-A1-0002
Rh 1.3456 m S
Hd 30.123 m
Z 20.2222 m
OK
d 69.023 m
D 69.023 m
h 0.3332 m
H 0.3332 m
Z 20.3332 m
S-O
P2
OK
Fixed pt No.0003
Feb/17/2009 10:33:28
Temp : C
Memo
:
END
1
YES
The measurement
of the route
is ended.
NO
OK
d 123.456 m
D 567.890 m
h 1.2345 m
H 4.5678 m
Z 24.5678 m
END
FIXEDP
OK
Feb/17/2009 12:23:58
Temp : 15.0 C
Memo
:
Meas. is ended.
1
