18. OUTPUTTING DATA
90
8. Align the cursor with the JOB to be output and
press {}.
The numbers to the right represent the
number of data items in each JOB.
“*” means the JOB has not been output to an
external device yet.
9. Output starts.
•Press {ESC} to cancel output.
10. Press {ESC} to return when "Completion" is
displayed.
PROCEDURE Outputting JOB data to an SD card
1. Open the external interface hatch cover.
2. Insert an SD card into the SD card slot.
3. Select “JOB” in <Management menu>.
4. Select “Comms output”.
5. Select format from "CSV 1", "CSV 2" or
"SDR2X".
6. Check that "Com. locat." is set to "SD".
7. Press [OK].
8. Align the cursor with the JOB to be output and
press {}.
9. Enter a file name and press [OK].
*JOB1 99
JOB2 20
JOB3 15
JOB4 10
JOB5 54
LAST
TOP
...P
OK
Format :CSV_1
Com.locat.:SD
COMM
DL-501_E.book 90
