GR-5 Configuration
GR-5 Operator’s Manual
3-36
7. Click the MINTER tab and configure the following settings
(Table 3-3), then click Apply (Figure 3-32).
Figure 3-33. Configure Receiver’s MINTER for Data Recording
Table 3-3. Receiver Parameters for the MINTER Tab
Parameter Base Receiver Rover Receiver
Recording
interval
Enter 15 seconds.
Elevation
mask angle
Enter 15 degrees.
File name
prefix
Enter a unique ID, such as the last 3 digits of receiver’s serial
number.
FN key mode (starts/stops data recording using the FUNCTION key)
For Static data recording,
select LED blink mode
switch.
For RTK data recording,
select Occupation mode
switch.
Initial data
collection
dynamic
mode
n/a Select Kinematic.
(This setting is for trajectory
surveys.)
Static
RTK Rover
