GR-5 Configuration
GR-5 Operator’s Manual
3-40
Figure 3-37. Base and Rover Configuration for RTK Surveys – Ports
12. Click the Advanced tab and then the Multipath tab. Set the
following parameters and click Apply (Figure 3-37 on
page 3-40).
• Code multipath reduction – enable
• Carrier multipath reduction – enable
Period (sec) Enter the interval at which the
receiver transmits differential
corrections.
n/a (Leave the default.)
Baud rate Select a baud rate to use for transmitting differential messages
from the receiver board to the modem module
The baud rate must match the modem’s serial port speed.
RTS/CTS Select to enable handshaking.
Table 3-4. Receiver Parameters for the Ports Tab (Continued)
Parameter Base Receiver Rover Receiver
Base
Rover
