Bluetooth Module Configuration
P/N 7010-1004
2-25
1. Using the RS232 cable, connect the serial port of the computer
(usually COM1) to the receiver’s serial port. If needed, turn on
the receiver and computer.
2. Run the TRU program and click Device Application Mode
Receiver Managing. Then click Device Connect (Figure 2-
18).
Figure 2-18. TRU – Connecting (1)
3. Select the COM Port of the computer to which the receiver is
connected and click Connect (Figure 2-19).
Figure 2-19. TRU – Connecting (2)
