8 CHECK AND ADJUSTMENT
8-14
8.8 Reference Frequency Checking Mode
The beam modulated by the reference frequency of EDM is emitted continuously.
This mode is used for frequency test mainly.
Operating procedure Operation Display
1 Press the [F5] key from the main menu.
[F5]
2 Press the [F6](↓) key to get to next page on
the display.
[F6]
3 Press the [F1] key.
The beam will be emitted.
[F1]
4 To return to the main menu icons, press the
[F1] (EXIT) key.
[F1]
Adjustment
F1 V0/Axis (Measurement)
F2 V0/Axis (Constant list)
F3 Date Time
F4 Instrument constant ↓
Adjustment
F1 FRQ check
↑
FRQ Check
During the signal output••
EXIT
To Next Page
