3-8
3 STANDARD MEASUREMENT MODE
3.2.6 Stake Out (S-O)
The difference between the measured distance and the distance preset is displayed.
The displayed value = Measured distance - Standard (Preset) distance
● Stake out operation can be performed for horizontal distance (HD), relative elevation (VD) or slope
distance (SD)
[Example: Relative elevation]
Operating procedure Operation Display
1 Press [F6](P1) key in the distance measuring
mode to get the function as in page 2.
[F6]
2 Press [F2](S-O) key and press [ENT] key.
3 Enter the relative elevation for stake out, and
press [ENT] key.
The measuring starts.
[F2]
[ENT]
Enter
value
[ENT]
4 Collimate the target (Prism).
The difference between the measured
distance and the standard distance is
displayed.
● To return to normal distance measurement mode, reset the standard distance to “ 0 ” or turn the power
switch off (Resume mode:OFF) once.
V : 90°10'20"
HR: 120°30'40" PSM 0.0
HD: PPM 0.0
VD: (m) F.R
MEAS MODE VH SD NEZ P1
↓
REC SO MEAN m/ft P2
↓
SO
HD : 0.000
VD :
EXIT BS
V : 90°10'20"
HR : 120°30'40" PSM 0.0
HD : < PPM 0.0
dVD : (m) *F.R
REC SO MEAN m/ft P2
↓
V : 90°10'20"
HR: 120°30'40" PSM 0.0
HD: < PPM 0.0
VD: (m) *F.N
REC SO MEAN m/ft P2
↓
