3 STANDARD MEASUREMENT MODE
3.1.2 Switching Horizontal Angle Right/Left
Make sure the mode is Angle measurement.
3.1.3 Measuring from the Required Horizontal Angle
1) Setting by Holding the Angle
Make sure the mode is angle measurement
.
.
Operating procedure Operation Display
1
Press [F6](
↓
)key to get the function as on
page 2.
[F6]
2
Press [F3](R/L) key.
The mode Horizontal angle Right (HR)
switches to (HL) mode.
[F3]
3
Measure the target in the same manner as
HR mode.
●
Every time pressing [F3](R/L) key is pressed, HR/HL mode switches.
Note: It is possible that the R/L switching is prohibited (R/L Rock). To set the R/L rock, see Chapter 7
“PARAMETERS SETTING MODE” .
Operating procedure Operation Display
1
Set the required horizontal angle, using
Horizontal tangent screw
Display
angle
2
Press [F5](HOLD) key.
[F5]
3
Collimate the target.*1)
Collimate
4
Press [F6](REL) key to finish holding the
horizontal angle.
The display turns back to normal angle
measurement mode.
[F6]
*1)To return to the previous mode, press [F1](ESC) key.
V : 87°55'45"
HR: 120°30'40"
SD HD NEZ 0SET HOLD P1
↓
REC HSET R/L V/% TILT P2
↓
V : 87°55'45"
HL: 239°29'15"
REC HSET R/L V/% TILT P2
↓
V : 90°10'20"
HR: 70°20'30"
SD HD NEZ 0SET HOLD P1
↓
Holding
HR: 70°20'30"
ESC REL
V : 90°10'20"
HR: 70°20'30"
SD HD NEZ 0SET HOLD P1
↓
To Next Page
