3 STANDARD MEASUREMENT MODE
3.5 DATA Output by soft key (REC)
It is also possible to output the result of measurement by pressing the soft key (REC).
[Example: Slope Distance measurement mode]
Confirm the slope distance measurement mode.
Operating procedure Operation Display
1 Press [F6]( ↓ ) key to get the function page as
2.
[F6]
2 Press [F1](REC) key.
Measuring will continue at this time.
[F1]
3 Press [F5](YES) key.
The measurement will start.
[F5]
After the measurement, the result will be hold
then recorded.
The screen will return to previous display.
V : 90°10'20"
HR: 120°30'40" PSM 0.0
SD: < PPM 0.0
(m) F.R
MEAS MODE VH SD NEZ P1
↓
REC SO MEAN m/ft P2 ↓
V : 90°10'20"
HR: 120°30'40" PSM 0.0
SD: < PPM 0.0
(m) F.R
[YES] [NO]
V : 90°10'20"
HR: 120°30'40" PSM 0.0
SD:
< PPM 0.0
(m) *F.R
REC SO MEAN m/ft P2
↓
V : 90°10'20"
HR: 120°30'40" PSM 0.0
SD: 123.456 PPM 0.0
(m) *F.R
REC > > >
V : 90°10'20"
HR: 120°30'40" PSM 0.0
SD: < PPM 0.0
(m) *F.R
REC SO MEAN m/ft P2 ↓
