2 PREPARATION FOR MEASUREMENT
2 PREPARATION FOR MEASUREMENT
2.1 Power Connection
(unnecessary if on-board Ni-MH battery BT-50Q is used)
See below for connecting the external battery pack.
● Battery pack BT-3Q
Power cord , PC-5 is used.
● Large capacity battery pack BT-3L
Power cord PC-6 is used.
Connector ends
PC-5
PC-6
PC-5
PC-6
BT-3Q
BT-3L
