1-6
1 NOMENCLATURE AND FUNCTIONS
Page Display
Soft
key
Function
Angle
measuring
SD F1 To be slope distance measuring mode.
HD F2 To be horizontal distance measuring mode.
NEZ F3 To be coordinate distance measuring mode.
0SET F4 Angle of horizontal is set to 0 00'00".
HOLD F5 Hold the horizontal angle.
REC F1 To be measurement data record mode.
HSET F2 Sets the horizontal angle by input value.
R/L F3 Switches R/L rotation of horizontal angle.
V/% F4 Switches the vertical angle and percent grade.
TILT F5
Sets the tilt function, ON/OFF.
If ON, the display shows tilt correction value.
Slope
distance
measuring
MEAS F1
Slope distance measuring starts.
Switches Continuous/ N-times (Single) measurement mode.
MODE F2 Set to the mode for Tracking , Coarse or Fine.
VH F3 To be angle measurement mode.
HD F4 To be horizontal distance measurement mode.
NEZ F5 To be coordinate measurement mode.
REC F1 To be measurement data record mode.
SO F2 To be stake out measurement mode.
MEAN F3 Sets the number of N-time measurement.
m/ft F4 Switches meter or feet unit.
Horizontal
distance
measuring
MEAS F1
Horizontal distance measuring starts.
Switches Continuous/ N-times (Single) measurement mode.
MODE F2 Set to the mode for Tracking , Coarse or Fine.
VH F3 To be angle measurement mode.
SD F4 To be slope distance measurement mode.
NEZ F5 To be coordinate measurement mode.
REC F1 To be measurement data record mode.
SO F2 To be stake out measurement mode.
MEAN F3 Sets the number of N-time measurement.
m/ft F4 Switches meter or feet unit.
Coordinate
measuring
MEAS F1
Coordinate measuring starts.
Switches Continuous/ N-times (Single) measurement mode.
MODE F2 Set to the mode for Tracking , Coarse or Fine.
VH F3 To be angle measurement mode.
SD F4 To be slope distance measurement mode.
HD F5 To be horizontal distance measurement mode.
REC F1 To be measurement data record mode.
HT F2 Sets an Instrument Height / Prism Height by input values.
MEAN F3 Sets the number of N-time measurement.
m/ft F4 Switches meter or feet unit.
SET F5 Sets an instrument coordinate point by input values.
