3-13
3 STANDARD MEASUREMENT MODE
The result will be shown.
*1) In case the coordinate of instrument point is not entered, (0,0,0) will be used as the default for the
instrument point.
The instrument height will be calculated as 0 when the instrument height is not entered.
The prism height will be calculated as 0 when the prism height is not set.
*2) Refer to Section 3.1.3“Measuring from the Required Horizontal Angle” or Section 4.1“Setting a Direction
Angle for Backsight Orientation”.
*3) Pressing [F1](MEAS) key, the measurement mode (Continuous measuring/ N-time measuring)
changes.
Pressing [F2](MODE) key, the measurement mode (FINE/ COARSE/TRACKING) changes.
● To return to the normal angle or distance measuring mode, press [F6](P
↓
) key to return to the function
as on page 1 and press [F3](VH),[F4](SD) or [F5](HD) key.
N : 12345.6789
E : -12345.6789 PSM 0.0
Z : 10.1234 PPM 0.0
(m) *F.R
MEAS MODE VH SD HD P2
↓
