4-4
4 PROGRAM MODE
5 Press [F6](SET) key.
Coordinate of P1 will be displayed.
[F6]
6 Press [F5](YES) key.
Coordinate of P1 will be decided.
[F5]
The display return to main menu.
Turn power off and move instrument to P1
( Prism P1 move to P0).
Power off
Move to
P1
7 After the instrument is set up at P1, turn
power on and be measurement possible.
Power on
Select
program
8 Press [F2](STORE) key.
[F2]
9 Press [F2](Recall NEZ) key.
10 Collimate P0, the former instrument point.
[F2]
Collimate
P
0
11 Press [F5](YES) key.
[F5]
The coordinates at P1 and direction angle
toward P
0 are set.
The display return to main menu.
12 Repeat the procedure 1 ~11 as much as you
wish.
*1)To reset the instrument height or prism height, press [F5](HT) key.
Store NEZ
N : 123.456 m
E : 12.345 m
Z : 1.234 m
> SET OK? YES NO
Complete
Programs
F1 BS p 4/8
F2 STORE p
F3 REM p
F4 MLM p MORE
Retaining a Coordinate
1.Store NEZ
2.Recall NEZ
Recall NEZ
HR: 300°10'20"
> Set OK?
YES NO
Complete
