4-9
4 PROGRAM MODE
4 Press [F6](SET) key.
[F6]
5 Collimate prism B and press [F1](MEAS) key.
Horizontal distance (HD) between the
instrument and prism B will be shown.
Collimate
B
[F1]
6 Press [F6]( SET) key.
The horizontal distance (dHD) relative
elevation (dVD) and slope distance between
prism A and B.
[F6]
7 To measure the distance between points A
and C, press [F2](HD) key. *1)
[F2]
8 Collimate point C (Prism C) and press
[F1](MEAS) key.
Horizontal distance (HD) between the
instrument and prism C will be shown.
Collimate
C
[F1]
9 Press [F6]( SET) key.
The horizontal distance (dHD) relative
elevation (dVD) and slope distance between
prism A and C.
[F6]
10 To measure the distance between points A
and D, repeat procedure
7 ~9. *1)
*1)To return to main menu , press[F1](EXIT) and [F5](YES) key.
MLM 1
Horizontal Distance 2
HD : m
MEAS SET
MLM 1
Horizontal Distance 2
HD * < m
MEAS SET
MLM 1
Horizontal Distance 2
HD * 246.912 m
MEAS SET
MLM 1
dHD : 123.456 m
dVD : 12.345 m
dSD : 12.456 m
EXIT HD
MLM 1
Horizontal Distance 2
HD : m
MEAS SET
MLM 1
Horizontal Distance 2
HD : < m
MEAS SET
MLM 1
Horizontal Distance 2
HD * 246.912 m
MEAS SET
MLM 1
dHD : 123.456 m
dVD : 12.345 m
dSD : 12.456 m
EXIT HD
