4-11
4 PROGRAM MODE
9 Recollimte the second target B using the
horizontal motion clamp and the horizontal
tangent screw.
10 Press [F6](HOLD) key.
The total of angle (Ht) and the average of
angle (Hm) are shown.
Recolli-
mate B
Doubled angle
11 Repeat 7 to10 to measure the desired
number of repetitions.
Quadrupled angle.
● Horizontal angle can be accumulated up to
(3600°00'00" - minimum reading)(horizontal angle right) or -(3600°00'00" - minimum
reading)(horizontal angle left). In case of 5 second reading, horizontal angle can be accumulated up to
±3599°59'55".
● To stop the repetition angle measurement mode, press [F1](EXIT) and [F5](YES) key.
Repetition Angle CNT[ 2]
Ht: 260°50'40"
Hm: 130°25'20"
EXIT 0SET REL HOLD
Repetition Angle CNT[ 4]
Ht: 521°41'20"
Hm: 130°25'20"
EXIT 0SET REL HOLD
