4 PROGRAM MODE
8 The instrument will measure and show the
horizontal angle, horizontal distance, and
vertical distance.
Type
Second
Ponit
Number
9 Enter the second point number to measure
and press the (ENT) key.
(ENT)
10 Enter the prism height for the second point
and press the (ENT) key.
Type
Prism
Height
(ENT)
11 Sight the instrument on the second point.
Once the instrument is locked, press [F5]
(YES) to measure the angle and distance.
The [F6] key will return back to step.
Sight
Second
Point
12 The instrument will measure and show the
horizontal angle, horizontal distance, and
vertical distance.
[F5]
13 After the instrument is complete measuring,
the screen showing the residual error
appears. Press [F5] to continue with the
resection routine or [F6] to start the resection
procedure, step 3).
14 After pressing [F5] (YES), the screen showing
the new coordinates appears. Pressing [F5]
stores the coordinates in the job and [F6]
returns back to step 3).
[F5]
15 The word (REC) on the display and returns
back to the Coordinate Data menu.
[F5]
HR : 0°00'00"
HD * <<<<
VD :
2nd
PT#:
Alpha SPC <- -> ↑ ↓
11
2nd
R.Ht:
EXIT BS
0.000
2nd
Pt:11
>Sight
YES NO
HR: 0°00'00"
HD* <<<<
VD:
Residual Error
dHD = 0.000 m
dZ = 0.000 m
>OK ?
YES NO
N: 515.773 m
E: 595.770 m
Z: 90.236 m
> Rec. New Point ?
YES NO
REC > > >
