RELATION BETWEEN SETTING OF ILLUMINATION/ FLASH LEVEL AND MAXIMUM RADIANCE
RELATION BETWEEN SETTING OF ILLUMINATION/
FLASH LEVEL AND MAXIMUM RADIANCE
When the maximum radiance is "1", the ratio of radiance is shown below in setting of illumination/
flash level.
Illumination level
Indicated
set value
Level ratio
10.277
20.366
30.497
40.669
51.000
Flash level
Indicated
set value
Level ratio
0.7 0.022
0.8 0.025
1.0 0.027
1.2 0.033
1.4 0.036
1.7 0.041
2.0 0.047
2.3 0.054
2.8 0.063
3.3 0.070
3.9 0.081
4.7 0.100
5.6 0.114
6.6 0.131
7.9 0.154
9.4 0.177
11 0.203
13 0.233
16 0.268
19 0.291
22 0.334
27 0.411
32 0.507
38 0.616
45 0.707
53 0.812
63 1.000
Illumination level
(In visible FA observation)
Indicated
set value
Level ratio
10.051
20.076
30.125
40.172
50.278
60.675
71.000
TRC-NW8F
Illumination level
Indicated
set value
Level ratio
10.277
20.366
30.497
40.669
51.000
Illumination level
(In visible FA observation)
Indicated
set value
Level ratio
10.051
20.076
30.125
40.172
50.278
60.675
71.000
TRC-NW8F
Illumination level
Indicated
set value
Level ratio
10.126
20.176
30.237
40.304
50.383
60.471
70.558
80.661
90.769
10 0.882
11 1.000
Illumination level
(In visible FA observation)
Indicated
set value
Level ratio
10.074
20.094
30.118
40.147
50.176
60.210
70.249
80.292
90.343
10 0.398
11 0.464
12 0.744
13 1.000
TRC-NW8F plus
