54
BASIC OPERATIONS
EXITING
1 Turn OFF(O) the on the instrument body and the external connection
device.
2 While operating the control lever, move the instrument body so that it comes just above
the base.
3 To prevent the base from moving suddenly, turn the base brake knob to the right to lock
the base.
For the next capture, turn the control lever and move the body to the center position.
The vertical center position of the instrument can be checked with the vertical position
mark.
When you are not going to use the instrument for a long period of time, remove the
power cords of the instrument body and external recording device from the power out-
lets, and remove all cords connecting the instrument to the external capture device.
This instrument adopts the power save method (P.41). If you are going to use the instru-
ment after a short pause period, it is recommended to use it without turning off the
.
To keep the cleanliness of the instrument, before taking a picture of the next patient,
remove the chinrest tissue at the top and clean the forehead rest and chinrest see page
96.
