OBJECTIVE OPERATIONS
PICTURE ANGLE CHANGE PHOTOGRAPHY
Setting the photography mode
Press the on condition that the Monitor screen appears in color pho-
tography and FA photography.
The magnification of the observed image is not changed and "30
°" is displayed at the left
side of the Monitor screen.
The picture angle change photography function cannot be used in FAF photography.
In the case of TRC-NW8F plus, this function can be used only when connected to the
personal computer to which the photography software is installed.
Setting the illumination level
As watching the observed image on the color LCD monitor, adjust its brightness with the
.
In TRC-NW8F plus, the auto illumination level adjustment function works and so the manual
adjustment is not necessary.
See "Setting the illumination level" on page 46.
Setting the flash level
Using the , set the flash level (in color photography) or ISO sensitivity (in
FA photography).
See "Setting the flash level" on page 47.
When changing the picture angle in color photography, the flash level for the picture
angle 30
° is automatically decreased by 2 steps compared with the picture angle 45°.
The flash level can be increased and decreased by 4 steps according to your wish.
When you want to change the setting, contact your dealer or TOPCON (see the back
cover).
Changing the diopter compensation lens
Push in the diopter compensation lens selector and change the diopter compensation lens to
(0).
See "Changing the diopter compensation lens" on page 48.
Centering and photography
Refer to "Centering and photography" on page 49.
PICTURE ANGLE SWITCH
ILLUMINATION LEVEL SWITCH
FLASH LEVEL SWITCH
