BASIC OPERATIONS
Setting the flash level
Set the flash level using the .
The compensation value can be checked with the flash level compensation display on the color
LCD monitor.
The flash level can be compensated in four steps in both the (+) and (-) directions from
the reference value.
When the flash level is the reference value, no compensation value is displayed.
When the instrument is first turned on, the flash level is set to the reference value.
You can adjust the reference value of the flash level in four steps in both (+) and (-)
directions.
The flash level display can also display the light intensity level (unit: W·s) in addition to
the compensation value.
For details about the flash level setting, contact your dealer or TOPCON (see the back
cover).
When the flash level compensation display is changed to the higher level by one step,
the flash level is increased by approx. 20%.
CAUTION
To avoid pain and discomfort to the patient and damage to the
patient's eye, do not brighten the photography light more than neces-
sary.
Flash level
compensation
display
To Next Page
