SPECIFICATIONS & PERFORMANCE
SYSTEM CLASSIFICATION
Types of protection against electric shocks: This instrument is classified as Class I
equipment.
Class I equipment does not depend only on basic insulation for protection against electric
shocks, but also provides a means of connection to a protective earth system of facilities so
that metal parts that come into contact do not become conductive while the basic insulation is
in failure.
Degree of protection against electric shocks: Type B applied part
Type B applied part is the applied part complying with the specified requirements of the Stan-
dard IEC 60601-1 to provide protection against electric shock, particularly regarding allowable
LEAKAGE CURRENT.
Degree of protection against harmful ingress of water: IPX0
The TRC-NW8F/TRC-NW8F plus has no protection against ingress of water. (The degree of
protection against harmful ingress of water defined in IEC 60529 is IPX0.)
Classification according to the method(s) of sterilization or disinfection recom-
mended by the manufacturer: not applicable.
The TRC-NW8F/TRC-NW8F plus has no part to be sterilized or to be disinfected.
Classification according to the degree of safety of application in the presence of a
flammable anesthetic mixture with air or with oxygen or nitrous oxide: Equipment
not suitable for use in the presence of a flammable anesthetic mixture with air or
with oxygen or nitrous oxide.
The TRC-NW8F/TRC-NW8F plus should be used in environments where no flammable anes-
thetics and/or flammable gases are present.
Classification according to the mode of operation: Continuous operation.
Continuous operation is the operation under normal load for an unlimited period, without the
specified limits of temperature being exceeded.
DIMENSIONS AND WEIGHT
Dimensions : 274mm (W) × 508mm (D) × 536 - 566mm (H)
Weight : 23.6kg (TRC-NW8F)
23.5kg (TRC-NW8F when the instrument is not equipped with the external fixa-
tion target)
23.9kg (TRC-NW8F plus)
23.8kg (TRC-NW8F plus when the instrument is not equipped with the external
fixation target)
INTENDED USE
The NON-MYDRIATIC RETINAL CAMERA TRC-NW8F/TRC-NW8F plus is intended for use in
capturing images of the retina and the anterior segment of the eye and presenting the data to
the eye care professional, with the use of a mydriatic or without use of a mydriatic.
